DC SERIES

DIMENSION AxBxC

MAX AIRFLOW

TD2510

25 x 25 x 10mm / 1 x 0.4 inch

2.~1.5 cfm

TD3010

30 x 30 x 10mm / 1.2 x 0.4 inch

4.2~2.5 cfm

TD4007

40 x 40 x 7mm / 1.6 x 0.3 inch

5.9~4.3 cfm

TD4010

40 x 40 x 10mm / 1.6 x 0.8 inch

5~2.5 cfm

TD4020

40 x 40 x 20mm / 1.6 x 0.8 inch

9.7~4.8 cfm

TD4510

45 x 45 x 10mm / 1.8 x 0.41 inch

7.6~4.8 cfm

TD5009

50 x 50 x 9mm / 2 x 0.35 inch

12~8 cfm

TD5012

50 x 50 x 12mm / 2 x 0.47 inch

14~7 cfm

TD5015

50 x 50 x 15mm / 2 x 0.6 inch

14~11 cfm

TD6010

60 x 60 x 11mm / 2.4 x 0.4 inch

15~10 cfm

TD6015

60 x 60 x 15mm / 2.4 x 0.6 inch

20~14 cfm

TD6020

60 x 60 x 20 / 2.4 x 0.8 inch

23~10 cfm

TD6025

60 x 60 x 25mm / 2.4 x 1 inch

38~12 cfm

TD8015

80 x 80 x 15mm / 3.15 x 0.6 inch

39~23 cfm

TD8020

80 x 80 x 20mm / 3.15 x 0.8 inch

40~27 cfm

TD8025

80 x 80 x 25 / 3.15 x 1 inch

48~22 cfm

TD9225

92 x 92 x 25mm/ 3.6 x 1 inch

66~25 cfm

TD9238AN

92 x 92 x 38mm / 3.6 x 1.5 inch

80~60 cfm

TD1225

120 x 120 x 25.5mm / 4.7 x 1 inch

86~45 cfm

TD1232AN

120 x 120 x 32mm / 4.7 x 1.25 inch

112~62 cfm

TD1238

120 x 120 x 38.5mm / 4.7 x 1.5 inch

118~65 cfm

TD1238AN

120 x 120 x 38.5mm / 4.7 x 1.5 inch

123~68 cfm

TD1238AP

120 x 120 x 38.5mm / 4.7 x 1.5 inch

135~70 cfm

TD12738

127 x 127 x 38.5mm / 5 x 1.5 inch

145~86 cfm

TD1751SAP

172 x 150 x 51mm / 6 x 2 inch

320~125 cfm

TD1751RAP

172 x 51mm / 6.77 x 2 inch

320~130 cfm

TD1751RPT

172 x 51mm / 6.8 x 2 inch

225~120 cfm

TD1755

172 x 150 x 55 / 5 x 2.17 inch

300~150 cfm

TD1865

180 x 180 x 65 mm / 7 x 2.5 inch

500~215 cfm

TD17689

176 x 176 x 89 mm / 7 x 3.5 inch

495~230 cfm

TD20070

200 x 70mm / 7.9 x 2.8 inch

590~280 cfm

TD8545R

254 x 89mm / 10 x 3.5 inch

850~350 cfm

TD25489

254 x 89mm / 10 x 3.5 inch

1050~890 cfm

TD26490

254 x 89mm / 10 x 3.5 inch

1050~700 cfm

TD8990

280 x 280 x 88.9mm / 11 x 3.5 inch

1200~780 cfm
